The JS series fan-shaped pouring machine is a pouring machine specially developed for small and medium-sized castings with short pouring times and high volume production. It is most suitable for high-speed vertical parting molding lines, and the pouring of ductile iron castings on vertical parting high-speed molding lines can reach 400 types / hour. This pouring machine is simple to operate, easy to use, and has high repeatability positioning accuracy when pouring. It pours the molten iron into the transfer ladle and forwarders the pouring machine by means of a forklift,trolley or molten iron conveyor. JS series pouring machine is a kind of left and right tilting pouring machine without heat insulation, the cross-section of the ladle is fan-shaped, and the outlet of molten iron is near the center of the fan-shaped circle, which is near the center of rotation. The tilt angle speed controlled by the servo motor moves according to the typical flow-time curve to achieve the best effect of simulating manual pouring. Fully mechanical transmission, simple structure. When converting products, the corresponding stored pouring parameters can be entered and can be seen on the operator table and make on-site adjustments. The pouring machine can move in both X and Y directions, and the downward trolley moves in the X direction (parallel to the molding line), and the frequency conversion system is controlled. The upward trolley moves in the Y direction (perpendicular to the molding line). It has the function of inoculant screw feeder and slag extraction.
